Coolgear CG-U3MINI4PH USB 3.1 4口Mini工业级Hub 支持ESD与电涌保护,含电源适配器
Mini工业级USB 3.1 Hub
支持ESD and Surge (静电与电涌)保护, 5Gbps数据传输带宽, 5V DC外接电源适配器供电。采用GL3510控制芯片,支持Apple 1A/2.1A/2.4A 与Samsung Galaxy快充。
结构紧凑的工业级hub
支持USB 3.1 Gen1 USB 规格, 5Gbps 数据传输带宽
5V DC 外接电源适配器供电
兼容支持 USB 2.0 / USB 1.1 data speeds
USB 3.1 4 Port Mini Hub Features
• Compliant with USB 3.1 Gen 1 Specification
• Upstream port supports Super-Speed (SS), High-Speed (HS) and Full-Speed (FS) traffic
• Downstream ports support SS, HS, FS, and Low-Speed (LS) traffic
• 1 control pipe and 1 interrupt pipe
• Backward compatible to USB specification Revision 2.0/1.1
• Compliant with USB Battery Charging Revision v1.2, supporting CDP, DCP, and ACA-Dock
• Downstream ports can be turned from a Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated Charging Port (DCP)
• Downstream devices can be charged while upstream VBUS is not present, which can be applied on wall charger applications
• Upstream port is capable of charging and data communicating simultaneously for portable devices supporting ACA-Dock or proprietary charging protocols
• Supporting Apple 1A/2.1A/2.4A and Samsung Galaxy devices fast-charging
• Compatible with Windows XP, 7, 8,10, and Mac OS X
Specifications
• Chip: GL3510
• USB 3.1 Gen Compliant
• Supports High Speed and Full Speed transmit and Receive
• Complies with USB-IF battery charging specification rev1.2
• Automatic switching between self-powered and bus-powered modes
• Built-in 5 to 3.3V and 5 to 1.2V regulator
• RISC-like architecture
• Item Dimensions: 2.86″(L 3.8″ w/ears) x 1.85(W) x 1.16(H)
Package Contents
• USB 3.1 4-Port Hub
• 4Amp 5V DC Mini-Switching Power Adapter
• USB A to B Cable for Hub
